BOSCH Mic LBB-1950

Harga Belum Termasuk PPN & Ongkos Kirim Luar Kota

Kontak Marketing Kami Untuk Dapatkan Harga Terbaik !

BOSCH LBB 1950/10 Plena Tabletop Unidirectional Condenser Microphone

▶Stylish tabletop unidirectional condenser
▶microphone on a flexible stem
▶Phantom powered by amplifier
▶Momentary or toggle PTT-key for calls with priority contact
▶Green LED, indicating microphone active
▶Stable metal base design with fixed 2 m cable and lockable DIN connector

The Plena tabletop microphone is a stylish, high quality tabletop unidirectional condenser microphone, mainly intended for making calls in a public address system. Its heavy metal base and rubber feet ensure stability on any flat surface. The special design also allows the unit to be neatly flush-mounted in desktops

Functions
The PTT-key (press-to-talk), not only switches on the microphone, but also provides priority contacts, that are compatible with the Plena range of amplifiers. Theswitching characteristic of the PTT-key can be configured internally for PTT-mode (on as long as pressed) or toggle-mode (press to switch on, press again to switch off). It is equipped with a fixed, flexible 2 m cable and a 5‑pin DIN connector for the balanced signal and the priority contacts. If the priority contacts are not required, the microphone can be connected to amplifiers with 3‑pin XLR-inputs, using the DIN to XLR adapter.
A green LED indicates when the microphone is active.

Controls and indicators
• PTT-key
• PTT status LED

Certifications and approvals
Safety acc. to EN 60065
Immunity acc. to EN 55103-2
Emission acc. to EN 55103-1

Technical specifications

Electrical

• Phantom power supply:
• Voltage range 12 to 48 V
• Current consumption <8 mA
• Performance :
• Sensitivity 0.7 mV @ 85 dB SPL (2 mV/Pa)
• Maximum input sound level 110 dB SPL
• Distortion <0.6% (maximum input)
• Input noise level (equiv.) 28 dB SPLA (S/N 66 dBA ref. 1 Pa)
• Frequency response 100 Hz to 16 kHz
• Output impedance 200 ohm

Mechanical

• Base dimensions (H x W x D) 40 x 100 x 235 mm (1.57 x 3.97 x 9.25 in)
• Weight Approx. 1 kg (2.2 lb)
• Color Charcoal with silver
• Stem length with mic 390 mm (15.35 in)
• Cable length 2 m (6.56 ft)

Environmental

• Operating temperature -10 ºC to +55 ºC (14 ºF to +131 ºF)
• Storage temperature -40 ºC to +70 ºC (-40 ºF to +158 ºF)
• Relative humidity <95%
